Elura Audiospeakers
Elura Audio OUT6.5X70
Equipment Sales & Professional Installation
MPN: OUT6.5X70
- 6.5" 2-way indoor/outdoor speaker
- 70V transformer with rotary taps
- 125 watt power handling
- Liquid-cooled aluminum dome tweeter
- Weather-resistant UV-treated cabinet
- Ratcheting mounting bracket
- Sold as a pair
Specifications
Specifications
| Woofer Size | 6.5 in |
|---|---|
| Woofer Material | Injection-molded metallic anodized cone w/ rubber surround |
| Tweeter Size | 1 in |
| Tweeter Material | Liquid-cooled aluminum dome |
| Power Handling | 5 - 125 Watts |
| Sensitivity | 90 dB |
| Frequency Range | 55 Hz - 20,000 Hz |
| Tap Settings (70 V) | 3.5W, 7.5W, 15W, 30W, 6Ω |
| Tap Settings (100 V) | 7W, 15W, 30W, 60W, 6Ω |
| Dispersion Angle (-6 dB) | 120° Horiz. x 110° Vert. (500 Hz - 5 kHz average) |
| Impedance | 6 ohms |
| Connection Type | Silicone-sleeved brass push terminals |
| Cabinet | Weather-resistant, UV treated, high-impact ABS composite |
| Grille | Powder coated aluminum |
| Mounting Bracket | Ratcheting aluminum |
| Overall Dimensions (W x H x D) | 8 in x 12.87 in x 7.25 in (203 mm x 327 mm x 184 mm) |
| Weight | 7 lbs (3.17 kg) |
| Colors | White and Black |
