Integraav-receivers
Integra DRX-8.4
Equipment Sales & Professional Installation
MPN: DRX8.4BMDD
- 11.4 Channels
- 150 watts per channel
- Symmetric Class A/B amplifier design
- Dual 32-bit ESS ES9026PRO DACs
- 8K/60 and 4K/120 HDMI 2.1 passthrough
- 7 HDMI inputs, 3 outputs with eARC
- Anti-resonant aluminum heat sinks
Specifications
Amplifier
| Power Output (8 ohm, 20Hz–20kHz, 2ch driven) | 150 W/ch |
|---|---|
| THD | 0.08% |
| Amplifier Design | Symmetric Class A/B |
| DAC | Dual 32-bit ESS ES9026PRO |
HDMI
| HDMI Inputs / Outputs | 7 in / 3 out with eARC |
|---|---|
| HDMI 2.1 | 6× 40Gbps inputs, 8K/60 and 4K/120 |
Dimensions & Weight
| Product Dimensions (W x H x D) | 17 1/8" x 7 13/16" x 18 1/2" |
|---|---|
| Product Weight | 49.6 lbs |
| Carton Dimensions (W x H x D) | 22 13/16" x 14 3/16" x 22 7/16" |
| Carton Weight | 33.1 lbs |
